FLASHBACK ARRESTOR
-
-
Brazil Type Flashback Arrestor
KS07-0017Features
Flashback arrestors are used to protect single cylinders, outlet points or pipelines and can be used for almost
all technical gases. The flashback arrestors are mountable in any orientation and are available with all connections
and in brass. High-quality materials and filters in the gas inlet provide long service life of flashback arrestors.
-Sintered metal flame arresting filter quenches the flame from severe flashbacks.
-Spring loaded non-return valve to prevent slow or sudden gas reverse flow.
- A flashback in the opposite direction to the flow is stopped and extinguish here.
